Engine Information

EPA certificated

Engine type: 4-stroke, single cylinder, air cooled

Displacement: 169cc

Max HP: 11hp/7500rpm

Max torque:8.2 lb ft/6000rpm

Bore x stroke: 2.4x2.28 inches

Climbing ability: 12 degrees

Ignition: C.D.I

Starting system: Electric

Battery: 12V 10Ah

Carburetor brand: Deli (Vacuum film)

Engine oil: SAE 15W-40

General Information

Clutch: Automatic CTV with reverse

Driveline / Driving wheel: Chain / Dual wheel drive

Suspension F / R: Double A-arm / swing-arm

Brakes, F / R: Both hydraulic brakes, Disc

Tires, F / R: 22x7-10 / 22x10-10

Wheel: Alumilum

Fuel capacity: 2.64 gal

Weight, G.W. / N.W.: 650 / 521 lbs

Max load: 500 lbs

Dimension Information

Wheelbase: 71 inches

OA L x W x H: 92.1x55x58.3 inches

Height to seat: 18.5 inches

Min ground clearance: 5.9 inches

Pedal to seat back distance: 36” to 42”

Key features:

Sporty stylish design

Articulating rear suspension equipped with anti-slop pull belts, much harder to roll over comparing to other rear solid axle machines

Alloy wheels with 22X7-10 front and 22X10-10 rear aggressive tires

Top LED light bar

Spare tire

High quality windshield

Side rearview mirrors

3 point automotive style retractable seat belt

LED headlight and turn signal

Electric start with kill switch

Fully automatic with reverse, high performance 169cc GY6 engine with internal F-N-R

Adjustable steering wheel

Individual sports seats

Bikini sunshade top

Adjustable driver seat: pedal to seat back adjustable from 36” to 42”

Rack and pinion steering wheel

Front and rear hydraulic disc brake

Large 22” front and rear tires

Parking brake

4-wheel stylish fenders

Large rear utility rack

Large gas tank
