Description
ENGINE / DRIVE TRAIN
| Displacement: | 169 cc |
| Type: | 4-Stroke (EFI) Electronic Fuel Injection Engine (OHC) with Ceramic-Coated Cylinder |
| Compression Ratio: | 10.2±0.2 :1 |
| Horsepower: | 12.2 hp - 7500 RPM |
| Max Torque: | 9.21 lb/ft - 5500 RPM |
| Cooling System: | Air |
| Transmission: | C.V.T. |
| Clutch: | Auto Centrifugal Type |
| Drive: | Belt |
| Starter: | Electrical Starter |
| Ignition: | CDI |
| Spark Plug: | CR7HSA |
| Battery Capacity: | 12V 8.6Ah (Closed Type, Maintenance-Free Battery) |
| Top Speed: | 65+ mph |
CHASSIS / SUSPENSION / BRAKES
| Frame: | High Strength Steel |
| Front Suspension: | Telescopic Fork |
| Rear Suspension: | Dual Shock |
| Front Brakes: | Disc Ø 260mm with ABS - Anti-lock Braking System |
| Rear Brakes: | Disc Ø 220 mm |
| Front Tires: | 100/90-14 |
| Rear Tires: | 110/80-14 |
| Wheel: | Aluminum |
CAPACIITIES / DIMENSIONS
| Weight Capacity: | 333 Lbs |
| Net Weight: | 295.4 lb |
| Fuel: | Unleaded (90 octane or higher) |
| Fuel Capacity: | 1.98 Gallons |
| Length: | 78.34" |
| Width: | 28.74" |
| Height: | 42.32" |
| Seat Height: | 30" |
| Wheelbase: | 53.14" |
| Age Recommendation: | 16+ |
ADDITIONAL INFO
| Government Certifications: | EPA & DOT Approved, C.A.R.B. Approved for CA |
| LED Lightings: | Jewel-like LED Projection Head Light, Front Position Lights and Rear Tail-light |
| QC 2.0 USB Charging Port: | Inside of the Front Glove Compartment. QC 2.0 charges devices at least 50% faster than QC 1.0 |
| Warranty: | 24 Months Unlimited Miles with Tire to Tire Parts & Labor Warranty Assurance |
| MPG: | 89 MPG* |
