| Engine Information |
| EPA and CARB certificated |
| Engine type: |
4-stroke, single cylinder, air cooled |
| Displacement: |
163cc |
| Max HP: |
5.5hp/3600rpm |
| Max torque: |
8 lb ft/3600rpm |
| Bore x stroke: |
2.6 x 1.8 inches |
|
|
| Climbing ability: |
12 degrees |
| Ignition: |
C.D.I |
| Starting system: |
Electric Start with Pull Start Backup |
| Battery: |
12V 9Ah |
| Carburetor brand: |
JF (RX) |
| Engine oil: |
SAE 15W-40 |
| General Information |
| Clutch: |
Automatic with reverse |
| Driveline / Driving wheel: |
Chain / Dual wheel drive |
| Suspension, F / R: |
Dual A-arm / Double Oil Damped Shock |
| Brakes |
Disc |
| Tires, F / R: |
145X70-6 / 16 X8-7 |
| Fuel capacity: |
1.2 gal |
| Weight, G.W. / N.W.: |
280 / 232 lbs |
| Max load: |
300 lbs |
| Dimension Information |
| Wheelbase: |
42.6 inches |
| OA L x W x H: |
58.7x38.2x48.8 inches |
| Height to seat: |
13.6 inches |
| Min ground clearance: |
4.02 inches |
| Pedal to seat back: 30” to 35”; Pedal can also adjusted to 3” or 6” shorter.
|
| |
|
Features: Live Axle, Two-wheel Drive, Electric Start w/Pull Start Back Up, LED Headlight, Remote Start/Kill, Adjustable Sports Seat, Adjustable Pedal, Five Point Safety Seatbelt, Speed Governor, Horn, Age Group: 4-12 yrs.
|
|
|
|
